RCinPower Smoox 2306.5 Motor (1880kV / 2280kV / 2580kV) (4-6S)

Description:

The building on the success of the GTS V2 motors, RcInPower have incorporated a unibell motor design in the smoox series. No only do these motors look the part, the high build quality and great performance make them one of the best motors around.

• 1880kV (orange) is best for 6S builds
• 2280kV (silver) is best for 4-5S builds
• 2580kV (blue) is best for 4S builds

Specifications

• Brand Name: RCINPOWER
• Model: SmooX 2306 Plus
• Item Name: 2306 1880KV 5-6S / 2280KV 2580KV 4-5S Motor
• KV: 1880KV / 2280KV / 2580KV ( Optional)
• Color: Blue / Orange/ Black ( Optional)
• Version: CW Screw Thread
• Quantity: One PC
• Configuration: 12N14P
• Stator Diameter: 23mm
• Stator Length: 6.6mm
• Shaft Diameter: 4mm ( Hollow)
• Idle Current(10V): 1.35A @ 1880KV ; 1.95A @ 2280KV ; 2.3A@2580KV
• Max. Con. Power (5S): 900W @ 1880KV; 850W @ 2280KV ; 1100W@2580KV
• Internal Resistance: 49m@ 1880KV ; 40m @ 2280KV ; 30m @2580KV
• Max. Current(5s): 36A @ 1880KV ; 40A @2280KV ; 55A @ 2580KV
• Cable Length: 15cm
• Motor Dimension(Dia*Len):29x30.5mm
• Weight: 33g ( 3cm wire)

Included

• 1 x Smoox 2306.5 plus Brushless Motor
• 1 x prop nut
